MKS-UM Multipurpose Dosimeter-Radiometer

 New generation meter for replacement of SVG2 designed for use by NATO forces
 In operational service with the Ukrainian Army and Law Enforcement Agencies of other countries
 Complies with the international military standards MIL-STD-810G and MIL-STD-461F as well as international standards ІЕС 60846 and ІЕС 60325
 Measures alpha, beta, gamma and X-ray radiation and has Integrated dual-system GPS/GLONASS receiver

MKS-UM is a full-range radiation survey device in field conditions. It is designed on the basis of MKS-U, which gained an excellent reputation under severe desert conditions during peacekeeping mission in the Middle East. It is suitable for use by military forces, particularly NATO forces.
MKS-UM measures alpha, beta, gamma and X-ray radiation.
The high protection rating IP67 allows the device to be used under harsh climatic conditions, and a rubber protective case can safeguard it from mechanical damage.

Description
The device measures dose rate of gamma radiation from background to emergency levels. It uses lithium-ion memory-effect-free battery. The display indicates a statistical error of measurements. Availability of the analog indicator and audio alarm of radiation intensity facilitates localization of radiation sources. It provides ease of use due to its small size and weight.

Its integrated dual-system GPS/GLONASS receiver enables MKS-UM to archive georeferenced measurement results.

The device has a nonvolatile memory of up to 4096 measurement results. The recorded results can be viewed on the display or transferred to the computer via the infrared port.

The device ensures a multilevel indication of battery discharge.

Storage battery of the device is charged with the help of the built-in charger from an integral solar battery, from an automobile battery or from an industrial network.

MKS-UM operates under the conditions of atmospheric precipitations, dusty conditions and in a wide temperature range. Back-lit display and controls allow the device to be used in dark areas.

Purpose of use
• Measures dose rate H*(10) of gamma and X-ray radiation
• Measures dose H*(10) of gamma and X-ray radiation
• Measures accumulation time of dose H*(10) of gamma and X-ray radiation
• Measures beta-particles surface flux density and beta-particles surface activity
• Measures alpha-particles surface flux density and alpha-particles surface activity
• Archives measurement results referring to the location coordinates

Branches of use
• LAW ENFORCEMENT AGENCIES
• EMERGENCY SERVICES AND CIVIL DEFENSE
• NUCLEAR POWER INDUSTRY
• RADIOACTIVE WASTE STORAGE SITES
• RADIOLOGICAL LABORATORIES

DKS-02 PN PRD CADMIUM Search Alarm Dosimeter

 High-sensitive search device of a new generation that is successfully used for radiation monitoring of borders of CIS member states according to the international technical assistance programs
 Complies with the international standards ANSI 42.32 and ANSI 42.33
 Built-in GPS/GLONASS receiver

A high-sensitivity device intended to detect and localize radioactive sources of gamma and neutron radiation. It is used by the border guard service and other law enforcement agencies to prevent illicit transfer of radioactive materials.

Description
The device comprises high sensitivity CsI scintillation detectors of gamma and LiI of neutron radiation with solid state (silicon) photomultiplier.

CADMIUM has the ingress protection rating IP67 and modern ergonomic design. It is equipped with a large color display with high resolution. The device has no “microphone effect” and ensures high thermal stability.

When threshold levels are exceeded, audible and vibrating alarms are generated, as well as light color indication of threshold levels exceeding (gamma radiation – red color, neutron – blue) with its duplication on the device’ front panel and end face.

The integrated GPS/GLONASS receiver and the new software make it possible to display the received radiation monitoring information on the electronic map.

The dosimeter can be connected to the PC via the USB port. It is powered from the built-in lithium polymer storage batteries that can be charged via the USB cable. Time of continuous operation is more than 200 hours.

Purpose of use
• Searches (detects and localizes) for radioactive and nuclear materials by their external gamma and neutron radiation
• Measures dose rate H*(10) of gamma, X-ray and neutron radiation
• Measures dose H*(10) of gamma and X-ray radiation
• Determines gamma, X-ray and neutron radiation intensity

Branches of use
• CUSTOMS AND BORDER SERVICES
• LAW ENFORCEMENT AGENCIES
• INDUSTRY
• RADIOACTIVE WASTE STORAGE SITES

 High-sensitive and compact identifier of a new generation that is successfully used for radiation monitoring of borders of CIS member states according to the international technical assistance programs
 Complies with the international standard ANSI 42.48
 Real-time spectrum identification
 Built-in GPS/GLONASS-receiver

A high-sensitivity and compact device intended to detect and localize radioactive and nuclear materials by their external gamma and neutron radiation, as well as identify radionuclides by an amplitude gamma spectrum. It is used by the border guard service and other law enforcement agencies to prevent illicit transfer of these materials. Also, SPECTRA is used at companies and institutions dealing with gamma and neutron radiation sources.

Description
The device comprises high sensitivity CsI scintillation detectors of gamma and LiI of neutron radiation with solid state (silicon) photomultiplier.

Spectrum identification is carried out in real time. SPECTRA identifies radionuclides with indication of a category that they belong to (in compliance with the IAEA requirements):
– medical radionuclides
18F, 67Ga, 51Cr, 75Se, 89Sr, 99Mo, 99mTc, 103Pd, 111In, 123I, 125I, 131I, 153Sm, 201Tl, 133Хе;
– industrial radionuclides:
57Co, 60Co, 133Ba, 137Cs, 192Ir,152Eu, 22Na, 241Am, 226Ra, 75Se;
– special nuclear materials:
233U, 235U, 237Np, Pu [Reactor grade plutonium (more than 6% 240Pu)];
– naturally occurring radioactive materials:
40K, 138La, 226Ra, 232Th-decay series and 238U-decay series.
Note: The list of nuclides may be extended if needed.

A brand new search algorithm provides high sensitivity of the device and its instant actuation at the slightest change of gamma or neutron background level. A new type detector ensures high thermal stability of the device and entirely eliminates the “microphone effect”.

The device is ergonomic and exceptionally user-friendly due to its compact size, large color display and ability to operate continuously for more than 200 hours when turned on. Ingress protection rating is IP67.

When threshold levels are exceeded, sound and vibrating alarms are generated, as well as light color indication of threshold levels exceeding (gamma radiation – red color, neutron – blue) with its duplication on the device’ front panel and end face.

The integrated GPS/GLONASS receiver and the new software make it possible to display the received radiation monitoring information on an electronic map.

The dosimeter can be connected to the PC via the USB port. The device stores and can transfer 250 complete gamma radiation spectra. It is powered from the built-in lithium polymer storage batteries that can be charged via the USB-cable.

Purpose of use
• Searches (detects and localizes) for and identifies radioactive and nuclear materials by their external gamma and neutron radiation
• Measures dose rate H*(10) of gamma, X-ray and neutron radiation
• Measures dose H*(10) of gamma and X-ray radiation
• Determines gamma and neutron radiation intensity
• Identifies a type of radionuclides by their amplitude gamma spectra (2048 channels)
• Saves amplitude gamma spectra and events in the nonvolatile memory

Branches of use
• CUSTOMS AND BORDER SERVICES
• EMERGENCY SERVICES AND CIVIL DEFENSE
• LAW ENFORCEMENT AGENCIES
• SANITARY DOSIMETRY AND ECOLOGY
• INDUSTRY
• RADIOACTIVE WASTE STORAGE SITES
